BevMax_Media_Programming_10_6_10 Page 28 of 106
08/15/2013
2. Port and Cup Sensors – Press the 2 Key to bring up a screen.
Data lists the current state concerning the Port Sensor.
Use the numeric Keys to Change the state concerning the
Port Sensor.
Data lists the current state concerning the Picker Cup
Sensor.
Use the numeric Keys to Change the state concerning the
Cup Sensor.
3. Platform Movement – Press the 3 Key to bring up a screen.
Press the 3 Key will bring up a screen allowing you to turn the components on and off.
Data listed is showing the current state of the various
switches as seen by the machine.
Press any column #, then press OK.
Press any tray #, then press OK.
Press Key 3 to cycle the plunger out & back.
4. Other Relays – Press the 4 Key to bring up a screen.
Press the 4 Key will bring up a screen allowing you to turn the components on and off.
Press a numeric Key will toggle the state of the chosen
component between On and Off.
Note: For the Lighting the side LEDs are controlled by this
switch. The top LEDs are not controlled by this switch.
Pressing the red X button will exit the group of functions.
Port and Cup Sensors
Port Sensor
Port Open Switch Off
Port Closed Switch On
Sensor Off
Vend Detect Off
1) Turn Port Sensor On >
2) Open Port >
Picker Cup Sensor
Sensor Off
Vend Detect Off
Picker Motor Home On
Picker Motor out Off
1) Turn Cup Sensor On >
2) Cycle Cup Plunger >
Platform Movement
X Home On
Y Home On
Picker Motor Home On
Picker Motor out Off
Port Open Off
Port Close On
Door Switch Opened
Motor Positions 10005 9919
Select ‘0’ to ‘home’ the platform
1) Move X 0
2) Move Y 0
3) Cycle Cup Plunger >
Other Relays
1) Turn Lighting Off >
2) Turn Refrigeration (Fan) Off >
3) Turn Compressor On >
4) Turn Cabinet Fan On >
