Crane BEVMAX 6 - Timed Event Modes; Time of Day Events

BevMax_Media_Programming_10_6_10 Page 64 of 106
08/15/2013
Press the 1 Key will scroll forward through the available options of settings to adjust. Press the 2 Key
will list any errors registered. Press the 3 Key will toggle the option setting shown from No to Yes.
Press the OK Key to save the setting you wish to use. Press the X Key to move backward 1 step in the
menu.
Press the 3 Key to move the Delivery Cup from the home
position to the Port opening.
Make sure the door switch is activated so that the motors are
powered. If this switch is not pulled out, then the motors
won’t move and nothing will happen.
Press the 5 Key to enter the Hook Offset option and open a
window that will allow you to change the setting. The factory
default setting is 93500.
Adjust hook Offset (right and left). To change the offset enter a new number (3310 counts = 1 inch) and
press the OK Key to save and display will show 4) Hook Offset #####. Press the 1 Key to scroll to the
Next step. Press the X Key to move backward 1 step in the menu.
Press the 1 Key and display will show Initial Setup is complete.
Close door to exit program.
(Info) TIMED EVENTS….. Press the info button to bring up a screen.
Press the information Key, bottom left on the numeric keypad, will bring up a screen listing the timed
events options.
Use the numeric Keys to choose an option.
Choosing an option will bring up the first screen for that option.
1. Press the 1 Key will bring up the first screen for Time of Day
Events.
Use the numeric Keys to choose the type of event you wish to create.
Choosing a type of event will bring up the first screen for that type of
event.
Press the 1 Key will bring up a screen listing options for Price Adjust.
Press the 1 Key here will create an event and begin a list of saved events that
can be set up as needed. If no events have been created you will see a
message – There is no Price Adjust event on this machine. You can create
one if it’s needed.
Use the numeric Keys to choose a created event to set up for use and another screen will come up
allowing you to configure the event to fit your needs.
Factory Setup
1) Next Step >
2) Diagnostics >
Hook Swipe Position Test
3) Move to Swipe Position >
4) Hook Offset 93500
Factory Setup
4) Hook Offset 93500
Factory Setup
Initial Setup is complete.
Timed Events
1) Time of Day Events >
2) Backup Events >
3) Power Saving Events >
Time of Day Events
1) Price Adjust >
2) Free Vend >
3) Inhibit >
Price Adjust
1) Create Event
2) Price Adjust #1
3) Price Adjust #2
