BevMax_Media_Programming_10_6_10 Page 89 of 106
08/15/2013
Check X Home On
Message with XY all
the way to home
position to the left.
Visual check. Where is picker cup
located?
HOME NOT HOME
In Test Menu, Platform Movement. Press
ā3ā key to cycle plunger. Is Picker Motor
Home Message with picker at the home
position?
YES NO
Cycle plunger multiple times to
ensure proper operation.
If Plunger is stuck in the
out or in position.
Refer to Delivery (Picker)
Cup Troubleshooting or
replace Cup Assembly.
Picker Motor Failure =
In Test menu, Platform
Movement, Picker Motor
message?
ON OFF
To Next Page
