Creality CR-10 S4 User Manual

1、Preheat
Method 1
Method 2
2、Feed Filament
Press and hold the extruder lever then insert the1.75mm filament through
the small hole of the extruder. Continue feeding until you see filament come out
the nozzle.
Tip：How to Replace the Filament？
1、Cutting filament near the Extruder and slowly feed new filament until they
are fed into the new filament.
2、Preheating the nozzle and withdraw the filament quickly and feed the new
filament.
8.Loading Filament
08

Creality CR-10 S4 Specifications

General

Build Volume	400 x 400 x 400 mm
Nozzle Diameter	0.4 mm
Filament Diameter	1.75 mm
Connectivity	SD card, USB
Frame Material	Aluminum
Bed Leveling	Manual
Printing Technology	FDM (Fused Deposition Modeling)
Heated Bed	Yes
Nozzle Temperature	Up to 250°C
Layer Resolution	0.1 - 0.4 mm
Printing Speed	Up to 180 mm/s, typically 40-80 mm/s
Supported Filament Types	PLA, ABS, TPU, Wood
Bed Temperature	Up to 100°C
Power Supply	110V/220V
