Creality CR-10 S4 User Manual

1. Introduction
01
1
1
9
10
11
12
13
14
15
16
17
18
19
20
2
3
4
5
6
7
8
2
3
Display Screen
TF Slot and USB Port
Nozzle Kit
Z Gantry Frame Platform
Filament Holder
Control Box
Nozzle Assembly
Connectiom
Platform Connection
Power Cable Connection
Extruder(E) Stepper
X Limit Switch
Z Limit Switch
Y Limit Switch
X Stepper
Z Stepper
Y Stepper
Control Knob
Voltage Selection
Base Frame
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20

Creality CR-10 S4 Specifications

General

Build Volume	400 x 400 x 400 mm
Nozzle Diameter	0.4 mm
Filament Diameter	1.75 mm
Connectivity	SD card, USB
Frame Material	Aluminum
Bed Leveling	Manual
Printing Technology	FDM (Fused Deposition Modeling)
Heated Bed	Yes
Nozzle Temperature	Up to 250°C
Layer Resolution	0.1 - 0.4 mm
Printing Speed	Up to 180 mm/s, typically 40-80 mm/s
Supported Filament Types	PLA, ABS, TPU, Wood
Bed Temperature	Up to 100°C
Power Supply	110V/220V
