Creality CR-10 S5 User Manual

1、Preheat
Method 1
Method 2
2、Feed Filament
Press and hold the extruder lever then insert the1.75mm filament through
the small hole of the extruder. Continue feeding until you see filament come out
the nozzle.
Tip：How to Replace the Filament？
1、Cutting filament near the Extruder and slowly feed new filament until they
are fed into the new filament.
2、Preheating the nozzle and withdraw the filament quickly and feed the new
filament.
8.Loading Filament
08

Creality CR-10 S5 Specifications

General

Build Volume	500 x 500 x 500 mm
Layer Resolution	0.1-0.4 mm
Printing Speed	Up to 200 mm/s
Filament Diameter	1.75 mm
Connectivity	SD card, USB
Frame Material	Aluminum
Display	LCD screen
Printing Technology	FDM (Fused Deposition Modeling)
Heated Bed	Yes
Bed Temperature	Up to 100°C
Nozzle Temperature	Up to 250°C
File Format	STL, OBJ, G-code
Nozzle Diameter	0.4 mm
Supported Filaments	PLA, ABS, TPU
Power Supply	AC 110-220V
