Creality CR-10 S5 User Manual

10
4. Repeat above steps 1- 2 times if necessary.
1. Prepare →Auto Home. Waiting for the nozzle to move to the left/ front of the platform.→ Prepare→Disable Steppers(Close stepper drive，release
motor）
2. Move the nozzle the front/left leveling screw and adjust the
platform height by turning the knob underneath. Use a piece of
A4 paper (standard printer paper) to assist with the adjustment,
making sure that the nozzle lightly scratches the paper.
3.
Complete the adjustment of the screw on all 4 corners.
1111111
11111
The nozzle is too far away from the
platform, so the consumables can not
adhere to the platform.
Filament are extruded evenly, just
sticking on the platform.
The nozzle is too close to the platform,
and the filament are not extruded
enough, even scraping the platform.
1 2
34
10.Platform Adjustment

Creality CR-10 S5 Specifications

General

Build Volume	500 x 500 x 500 mm
Layer Resolution	0.1-0.4 mm
Printing Speed	Up to 200 mm/s
Filament Diameter	1.75 mm
Connectivity	SD card, USB
Frame Material	Aluminum
Display	LCD screen
Printing Technology	FDM (Fused Deposition Modeling)
Heated Bed	Yes
Bed Temperature	Up to 100°C
Nozzle Temperature	Up to 250°C
File Format	STL, OBJ, G-code
Nozzle Diameter	0.4 mm
Supported Filaments	PLA, ABS, TPU
Power Supply	AC 110-220V
