5 Inch Lectern/Wall Mount Touchpanel Crestron Isys
TPS-2000L
Audio Digital Reserved Join Numbers for TPS-2000L Touchpanels
JOIN
NUMBER
FUNCTION VALUE DIRECTION
17300 Audio On I/O
17301 Audio Off I/O
17302 Key Click On I/O
17303 Key Click Off I/O
17304 Key Click Volume Up I
17305 Key Click Volume Down I
17306 Line Audio On I/O
17307 Line Audio Off I/O
17308 Line Audio Volume Up I
17309 Line Audio Volume Down I
17312 WAV Audio On I/O
17313 WAV Audio Off I/O
17314 Internal Volume Increase I
17315 Internal Volume Decrease I
17318 Microphone AGC Setting AGC On I/O
17319 Microphone AGC Setting AGC Off I/O
17320 WAV File Play I
17325 Audio Bass Up I
17326 Audio Bass Down I
17327 Audio Treble Up I
17328 Audio Treble Down I
17329 Master Volume Up I
17330 Master Volume Down I
Analog Reserved Join Numbers for TPS-2000L Touchpanels
NUMBER FUNCTION
DIRECTION
17100 Video Brightness I/O
17101 Video Contrast I/O
17102 Video Saturation I/O
17103 Video Hue I/O
17104
Horizontal Pan of Video Image (change the value with the
physical movement of one's touch on the screen)
I/O
17105
Vertical Pan of Video Image (change the value with the
physical movement of one's touch on the screen)
I/O
17200 System Cresnet ID I/O
17202 System Power Down Timeout I/O
17203 System Standby Timeout I/O
17217 Screen LCD Bias I/O
17218 Auto Brightness Threshold I/O
17219 Auto Brightness Current Value I/O
17300 Key Click Volume I/O
17301 Audio Line Volume I/O
17302 Internal Volume I/O
17305 Audio Bass I/O
17306 Audio Treble I/O
17307 Master Volume I/O
28 • 5 Inch Lectern/Wall Mount Touchpanel: TPS-2000L Operations Guide – DOC. 5972A
