4 • TSW-70 Series ProductManual—Doc.8550E
Running the Crestron Scheduling App, the TSW-570 integrates directly with Crestron Fusion®
software, Microsoft Exchange Server® software (for users of Outlook® software and Office365®
software), the Google Calendar™ calendaring app (including G Suite™ software), CollegeNET®
25Live® scheduling software, or Ad Astra™ software. IBM® Notes® software is also supported
through a Crestron Fusion on-premises server.
Crestron Home OSControl
The TSW-570 may be used to control a Crestron Home™ OS whole home solution. Select the
Crestron Home app from the touch screen to control lighting, shades, climate, media, security,
and cameras, including the ability to create and recall scenes that create a desired ambiance
throughout a home. A TSW-570 may be installed in each room to provide easy access to various
Crestron Home functions for both the room and the home.
Web Browsing
Using its built-in web browser, the TSW-570 provides access to online program guides and other
web-based services, and it can be used to control DVRs and other devices without having to pick
up a separate tablet or smartphone.
3
Wired Connectivity
An Ethernet LAN connection is all that is required to wire the TSW-570, containing all control,
video, and power signals within a single wire.
Power over Ethernet
Using PoE technology, the TSW-570 gets its operating power directly through the network cable.
PoE (Power over Ethernet) eliminates the need for a local power supply or any dedicated power
wiring. Crestron PoE switches (CEN-SW-POE-5 or CEN-SWPOE-16
1
) offer a total networking
solution with built-in PoE for multiple touch screens. A PoE Injector (PWE-4803RU
1
) is also
available to support a single touch screen.
NOTE: Refer to the “Power” specifications for more details.
Room Scheduling Accessories
The TSW-570 provides dual high-speed USB2.0ports for connecting supported Crestron room
scheduling hallway sign accessories to the touch screen. The SSW, SSW-EL, SSC, and SSC-EL
series hallway signs feature a twosided acrylic sign face that can be custom engraved with the
room name or number. The SIW-100 offers a lower profile wall mount status indicator.
1
Enterprise-Grade Security
Crestron touch screens employ enterprise-grade networking with robust security features such
as 802.1X authentication, TLS encryption, HTTPS connectivity, and Active Directory® service
integration. These features are imperative to protect your network against service interruptions
and malicious intrusions, and to ensure compliance with your organization’s network policies.
Cloud-based provisioning and management streamlines the process of configuring, monitoring,
and updating every touch screen on the network. Additional support for SNMP allows the touch
screen to be monitored by your IT administrator.
