18 • TSW-70 Series ProductManual—Doc.8550E
Additional wall mounting options are afforded using the optional TSW-UMB-70 universal
mounting bracket, TSW-UMB-70-PMK preconstruction mounting kit, and TSW-UMB-70-BBI
back box.
3,9
OptionalMounting Accessories
The TSW-770 supports numerous optional mounting accessories that allow the touch screen to
be installed in all kinds of installations:
l
The TSW-770-MSMK multisurface mount kit allows a TSW-770 touch screen to be
mounted directly to virtually any flat surface, which is ideal for mounting at the entrance
to a meeting space for room scheduling applications.
3
l
The TSW-770/1070-MUMKallowsthe touch screen to be attached to the mullion of an
interior glass wall, window, or partition.
3
l
The TSW-770/1070-RMB-1andTSW-770/1070-RMB-2 retrofit mounting brackets allow
for retrofit installations in place of an older Crestron touch screen (APAD, CT-1000,
LC-1000, TPS-4L, or TPS-2000L) without having to tear out the old mounting hardware
or patch the wall.
3
l
The TSW-570/770-RMK-1 rack mount kit allows the touch screen to be mounted into a 19
in. rack. When installed, the touch screen occupies three rack spaces.
3
l
The TSW-770-FP face plate hides the electrical box from view when replacing a TSW-760
or TSS-7 series touch screen with a TSW-770 series touch screen.
3
The TSW-770 is also compatible with Wall-Smart® flush wall mount products via a partnership
with Crestron. For more information on supported Wall-Smart hardware, click here.
