Product Manual — Doc. 8550E TSW-70 Series • 23
Crestron Home OSControl
The TSW-770-GV may be used to control a Crestron Home™ OS whole home solution. Select the
Crestron Home app from the touch screen to control lighting, shades, climate, media, security,
and cameras, including the ability to create and recall scenes that create a desired ambiance
throughout a home. A TSW-770-GV may be installed in each room to provide easy access to
various Crestron Home functions for both the room and the home.
Web Browsing
Using its built-in web browser, the TSW-770-GV provides access to online program guides and
other web-based services, and it can be used to control DVRs and other devices without having
to pick up a separate tablet or smartphone.
1
Wired Connectivity
An Ethernet LAN connection is all that is required to wire the TSW-770-GV, containing all
control, video, intercom, and power signals within a single wire.
Power over Ethernet
Using PoE technology, the TSW-770-GV gets its operating power directly through the network
cable. PoE (Power over Ethernet) eliminates the need for a local power supply or any dedicated
power wiring. Crestron PoE switches (CEN-SW-POE-5 or CEN-SWPOE-16) offer a total
networking solution with built-in PoE for multiple touch screens. A PoE Injector (PWE-4803RU) is
also available to support a single touch screen.
NOTE: Refer to the “Power” specifications for more details.
Room Scheduling Accessories
The TSW-770-GV provides dual high-speed USB2.0 ports for connecting supported Crestron
room scheduling accessories to the touch screen.
2
l
The series light bars provide a 180° visual indication of a room’s availability status,
illuminating green if the room is available and red when reserved, with options for custom
color mixing and programming.
2
l
The SSW, SSW-EL, SSC, and SSC-EL series hallway signs feature a twosidedacrylic sign
face that can be custom engraved with the room name or number. The SIW-100 offers a
lower profile wall mount status indicator.
2
Enterprise-Grade Security
Crestron touch screens employ enterprise-grade networking with robust security features such
as 802.1X authentication, TLS encryption, HTTPS connectivity, and Active Directory® service
integration. These features are imperative to protect your network against service interruptions
and malicious intrusions, and to ensure compliance with your organization’s network policies.
Cloud-based provisioning and management streamlines the process of configuring, monitoring,
and updating every touch screen on the network. Additional support for SNMP allows the touch
screen to be monitored by your IT administrator.
