56 • TSW-70 Series ProductManual—Doc.8550E
Streaming Decoder
Video Formats H.265, H.264 (MPEG-4 part 10 AVC, MJPEG)
Audio Formats AACStereo
Bitrates Upto 25 Mbps (20 Mbps maximum recommended)
Input Resolutions Up to 1920x1080@30fps
Protocol RTSP
Connectors
LANPoE (1) 8-pin RJ45 connector, female, with 2 LEDindicators;
100BASE-TX Ethernet port;
PoE+ PD port;
Green and yellow LEDs indicate Ethernet port status
USB (2)USBType Aconnectors, female;
USB 2.0 host ports;
For optional room scheduling accessories
Power
PoE(Powerover
Ethernet)
IEEE 802.3at Type 2 compliant PoE+ PD (Powered Device);
Requests 15 W from an 802.3at Type 2 PSE with LLDP advanced power
management;
Requests 30 W (PoE+Class4) from an 802.3at Type 2 PSE without LLDP;
Requests 15.4 W (PoEClass0) from an 802.3af (or 802.3at Type 1)PSE
Environmental
Temperature 32 to 104 °F (0 to 40 °C)
Humidity 10% to 95% RH (noncondensing)
Heat Dissipation 44 BTU/hr
Construction
Housing Plastic, smooth black or white finish, edge-to-edge glass with black or white
surround
Mounting Surface mount over a 3-3/4 in. H x 2 in. W(96mm H x 51 mm W) cutout;
2-13/16 in. (72 mm) minimum mounting depth;
1-1/4 in. (32 mm) maximum mounting surface thickness;
Pre/postconstruction mounting bracket assembly included;
Back box option sold separately
