Crouzet CTR48 Series User Manual

18
english
9. Scope of delivery
Preset counter
Mounting clip
Operating instructions
10. Ordering code
87.621.xxx
Supply voltage
1 = 10 .. 30 VDC
2 = 24VAC +/-10%
5 = 90 .. 260 VAC
Presets
1 = 1 preset
2 = 2 presets
LCD version
1 = amber backlight-
ing
2 = red-green
11. Frequencies
11.1 Pulse counter
Opérations rS0/rSP2 rSA0 rSAP2
de sortie bCrS0 bCrSA0
bCrSP2 bCrSA2
tCrS0 tCrSA0
tCrSP2 tCrSA2
MurS0
dir 40 kHz 5,2 kHz 4,2 kHz
AS 20 kHz 4,4 kHz 4,2 kHz
AA
PP 20 kHz 2,2 kHz 2,1 kHz
PP2
PP4 15 kHz 1,1 kHz 1,0 kHz
11.2 Frequency meter
tA.A
tA.AS 40 kHz
tA.AA
Quad 20 kHz
NOTE: Switching levels of the inputs
Switching levels with AC and DC power
supply:
HTL level Low: 0 .. 2 VDC
High: 8 .. 30 VDC
