Crown Macro-Tech MA-3600VZ Service Manual

MA-3600VZ Service Manual
Parts 5-34
130366-1 Rev. A
©2000 Crown International, Inc.
Capacitors
C1 C 3913-8 470µF
C2 C 4303-1 1000µF
C4 C 6802-0 .47µF
C7 C 6804-6 .1µF
C100 C200 C 8576-8 100µF
C101 C201 C 6227-0 20pF
C102 C202 C 8576-8 100µF
C103 C203 C 6805-3 .022µF
C104 C204 C 6805-3 .022µF
C105 C205 C 6813-7 27pF
C106 C206 C 6813-7 27pF
C107 C207 C 7870-6 .33µF
C108 C208 C 6813-7 27pF
C109 C209 C 8576-8 100µF
C110 C210 C 5362-6 2.2µF
C112 C212 C 8991-9 .47µF
C113 C213 C 8530-5 12µF
C114 C214 C 8576-8 100µF
C115 C215 C 8576-8 100µF
C116 C216 C 8530-5 12µF
C117 C217 C 8991-9 .47µF
C118 C218 C 6813-7 27pF
C119 C219 C 6802-0 .47µF
C122 C222 C 5194-3 68pF
C123 C223 C 6808-7 470pF
C124 C224 C 5194-3 68pF
C129 C229 C 6812-9 47pF
C130 C230 C 6814-5 12pF
C131 C231 C 6814-5 12pF
C132 C232 C 6807-9 .001µF
C133 C233 C 6813-7 27pF
C134 C234 C 6805-3 .022µF
C135 C235 C 6805-3 .022µF
C136 C236 C 6808-7 470pF
C137 C237 C 6808-7 470pF
C138 C238 C 6812-9 47pF
C139 C239 C 6812-9 47pF
C140 C240 C 6814-5 12pF
C141 C241 C 6814-5 12pF
C143 C243 C 6808-7 470pF
C144 C244 C 8576-8 100µF
C145 C245 C 6812-9 47pF
C146 C246 C 6950-7 82pF
C148 C248 C 6808-7 470pF
C149 C249 C 6807-9 .001µF
C151 C251 C 6806-1 .01µF
C152 C252 C 6811-1 100pF
C153 C253 C 6804-6 .1µF
C154 C254 C 8426-6 .1µF
C155 C255 C 6804-6 .1µF
C156 C256 C 6804-6 .1µF
C157 C257 C 6813-7 27pF
C159 C259 C 8551-1 .01µF
C160 C260 C 6811-1 100pF
Diodes
D1 C 2851-1 1N4004
D2 C 2851-1 1N4004
D3 C 2851-1 1N4004
D4 C 2851-1 1N4004
D5 C 2851-1 1N4004
D6 C 2851-1 1N4004
D7 C 2851-1 1N4004
D100 D200 C 3181-2 1N4148
D101 D201 C 3181-2 1N4148
D108 D208 C 3181-2 1N4148
D109 D209 C 3181-2 1N4148
D110 D210 C 3181-2 1N4148
D112 D212 C 3181-2 1N4148
D113 D213 C 3181-2 1N4148
D114 D214 C 8158-5 1SS143
D115 D215 C 8158-5 1SS143
D122 D222 C 3181-2 1N4148
D124 D224 C 3181-2 1N4148
D125 D225 C 3181-2 1N4148
D126 D226 C 8158-5 1SS143
D127 D227 C 8158-5 1SS143
D129 D229 C 5061-4 1N3070
D130 D230 C 3181-2 1N4148
D131 D231 C 3181-2 1N4148
D132 D232 C 3181-2 1N4148
D133 D233 C 3181-2 1N4148
LED's
E100 E200 C 9857-1 Red
E101 E201 C 9857-1 Red
Resistor Networks
N101 N201 D 8279-8 Resistor Network
N102 N202 D 7639-4 7 Pin SIP
Transistors
Q100 Q200 D 2961-7 2961
Q101 Q201 C 8104-9 MPSW92
Q102 Q202 C 8103-1 MPSW42
Q103 Q203 C 3625-8 2N4125
Q104 Q204 C 8104-9 MPSW92
Q105 Q205 C 8104-9 MPSW92
Q106 Q206 C 3625-8 2N4125
Q43107-4 Main PWA (D 8102-2 PWB) Parts List
