Parts 5-35
130366-1 Rev. A
MA-3600VZ Service Manual
©2000 Crown International, Inc.
Q111 Q211 C 8103-1 MPSW42
Q112 Q212 C 3625-8 2N4125
Q113 Q213 C 3625-8 2N4125
Q114 Q214 C 7458-0 2N4123
Q115 Q215 D 2962-5 MPS8097
Q116 Q216 C 3786-8 PN4250A
Q117 Q217 D 2961-7 2961
Q118 Q218 D 2961-7 2961
Q119 Q219 C 3625-8 2N4125
Q120 Q220 C 3625-8 2N4125
Q121 Q221 C 7458-0 2N4123
Q122 Q222 C 7458-0 2N4123
Q123 Q223 C 3625-8 2N4125
Q124 Q224 C 3786-8 PN4250A
Q125 Q225 C 5891-4 MTS105
Q126 Q226 C 3625-8 2N4125
Q127 Q227 C 7458-0 2N4123
Q128 Q228 C 3625-8 2N4125
Q129 Q229 C 7458-0 2N4123
Q130 Q230 C 3625-8 2N4125
Resistors
R1 A10265-22121 22.1K 1%
R4 A10265-28721 28.7K 1%
R7 A10266-4331 43K
R8 A10265-75021 75K 1%
R17 A10265-75021 75K 1%
R18 A10266-4331 43K
R19 A10266-2R72 2.7 .5W
R101 R201 A10265-24911 2.49K 1%
R102 R202 A10266-5111 510
R103 R203 A10265-49923 49.9K 1W 1%
R104 R204 A10265-26711 2.67K 1%
R105 R205 A10265-26711 2.67K 1%
R106 R206 A10265-11821 11.8K 1%
R107 R207 A10266-9131 91K
R108 R208 A10266-8211 820
R109 R209 A10265-75R01 75 1%
R110 R210 A10266-9131 91K
R111 R211 A10265-11821 11.8K 1%
R112 R212 A10265-49921 49.9K 1%
R113 R213 A10265-48711 4.87K 1%
R114 R214 A10265-48711 4.87K 1%
R115 R215 A10266-5141 510K
R116 R216 A10266-3351 3.3M
R117 R217 A10266-4731 47K
R118 R218 A10265-28701 287 1%
R119 R219 A10265-16211 1.62K 1%
R120 R220 A10265-28701 287 1%
R121 R221 C 5062-2 100K Pot
R122 R222 A10266-2041 200K
R123 R223 A10266-2432 24K .5W
R124 R224 A10265-11021 11K 1%
R125 R225 A10266-1011 100
R126 R226 A10266-1011 100
R127 R227 A10265-11021 11K 1%
R128 R228 A10266-1331 13K
R129 R229 A10266-1041 100K
R130 R230 A10266-1041 100K
R131 R231 A10266-1331 13K
R132 R232 C 5062-2 100K Pot
R133 R233 A10266-2741 270K
R134 R234 A10266-2432 24K .5W
R135 R235 A10266-1011 100
R136 R236 A10265-11021 11K 1%
R137 R237 A10266-1011 100
R138 R238 A10265-11021 11K 1%
R139 R239 A10266-8211 820
R140 R240 A10265-75R01 75 1%
R141 R241 A10266-1541 150K
R142 R242 A10266-1541 150K
R143 R243 A10266-4711 470
R144 R244 A10266-4711 470
R145 R245 A10266-4711 470
R146 R246 A10265-11821 11.8K 1%
R147 R247 A10124-24 Jumper Wire
R148 R248 A10265-19111 1.91k 1%
R149 R249 A10266-5102 51 .5W
R150 R250 A10265-19111 1.91k 1%
R151 R251 A10265-11821 11.8k 1%
R152 R252 A10265-11821 11.8K 1%
R153 R253 A10124-24 Jumper Wire
R154 R254 A10266-5601 56
R155 R255 A10266-4731 47K
R156 R256 A10266-1321 1.3K
R157 R257 A10266-1321 1.3K
R158 R258 A10265-11821 11.8K 1%
R159 R259 A10266-1331 13K
R160 R260 A10266-5601 56
R161 R261 A10266-4701 47
R162 R262 A10266-4701 47
R163 R263 A10266-5601 56
R164 R264 A10266-4711 470
R165 R265 A10266-4711 470
R166 R266 A10266-4711 470
R167 R267 A10265-10011 1K 1%
R168 R268 A10265-97601 976 1%
R169 R269 A10266-1041 100K
R170 R270 A10265-10011 1K 1%
R171 R271 A10265-95301 953 1%
R172 R272 A10266-1041 100K
R173 R273 A10266-5601 56
R174 R274 A10265-11821 11.8K 1%
Q43107-4 Main PWA (D 8102-2 PWB) Parts List Cont.
