Page #56 background image
MA-3600VZ Service Manual
Parts 5-36
130366-1 Rev. A
©2000 Crown International, Inc.
R179 R279 A10265-10011 1K 1%
R180 R280 A10266-4711 470
R181 R281 A10265-48711 4.87K
R182 R282 A10266-2201 22
R183 R283 A10265-24911 2.49K 1%
R184 R284 A10266-4741 470K
R185 R285 A10265-24911 2.49K 1%
R186 R286 A10266-2751 2.7M
R187 R287 A10266-3321 3.3K
R188 R288 A10266-3321 3.3K
R189 R289 A10266-2731 27K
R190 R290 A10266-2051 2M
R191 R291 A10266-3331 33K
R192 R292 A10266-6221 6.2K
R193 R293 A10266-6221 6.2K
R194 R294 A10265-49921 49.9K 1%
R195 R295 A10266-4701 47
R196 R296 A10266-3921 3.9K
R197 R297 A10265-10021 10K 1%
R198 R298 A10266-3921 3.9K
R199 R299 A10265-10021 10K 1%
R500 R600 A10266-1541 150K
R501 R601 A10266-1541 150K
R502 R602 A10266-1541 150K
R503 R603 A10266-4702 47 .5W
R504 R604 A10266-5141 510K
R505 R605 A10266-5141 510K
R506 R606 A10266-1521 1.5K
R507 R607 A10266-4711 470
R508 R608 A10266-1051 1M
R509 R609 A10265-10021 10K 1%
R510 R610 A10265-10021 10K 1%
R511 R611 A10265-10021 10K 1%
R512 R612 C 9079-2 200
R513 R613 A10265-10021 10K 1%
R514 R614 C 7340-0 24 5W
R516 R616 A10266-1051 1M
R517 R617 A10265-75R01 75 1%
R518 R618 A10265-75R01 75 1%
R519 R619 A10265-16911 1.69K 1%
R520 R620 A10266-1521 1.5K
R521 R621 A10266-9121 9.1K
R522 R622 A10266-5641 560K
R523 R623 A10266-1521 1.5K
R524 R624 A10266-5641 560K
R525 R625 A10265-95311 9.53K 1%
Switches
S2 C 7325-1 DPDT, GND LFT
S3 C 7960-5 Input Sensitivity
S4 C 6781-6 6P3T, MONO
Integrated Circuits
U1 C 5095-2 7815, +15V Reg
U2 C 5096-0 7915, -15V Reg
U100 U200 C 6911-9 UPA75
U101 U201 C 6411-0 H11C2
U102 U202 C 4345-2 LM339
U103 U203 C 6910-1 UPA76
U104 U204 C 7558-7 33079
Miscellaneous
(4) C 1811-6 4" Cable Tie
(2) C 9494-3 Heatsink, TO220
J2 C 4508-5 IC Socket, 16 Pin
J100 J200 C 8432-4 3 Pin Phone Jack
J100X J200X C 6778-2 Phone Jack Cover
J500 J800 D 8395-2 7.75" 12 Cond. Cable
J600 J700 D 8397-8 2.5" 12 Cond. Cable
P1 C 7593-4 Header, 5 Pin
P6 C 8418-3 Header, 3 PIn Gold
P11 C 7526-4 Header, 3 Pos
P101 P201 C 7592-6 Header, 3 Pos
(1) C 9450-5 Header, 6 Pos, TP1
(2) C 8019-9 IC Socket, 6 Pin
(4) C 3450-1 IC Socket, 14 Pin
Q43107-4 Main PWA (D 8102-2 PWB) Parts List Cont.
