CRT Space-U - PC Connecting for Programming

9
»
External speaker adopt double port BTL, please care about the
connecting way
. The speaker can not connect with the ground,
otherwise the speaker will be fault. The wrong connecting way
as the following picture.
PC Connecting
To utilize the optional CRT software, you must rst connect the
transceiver to your PC then using an optional programming cable .
Please use CRT software for programming.
»
Ask your dealer about purchasing a Programming Cable .
EX
T
S
P
A
N
T
Ground
Error
MS120
