3.3 Power Connection
Mobile Operation
The vehicle battery must have a nominal rating of 12V. Never connect
the transceiver to a 24V battery. Be sure to use a 12V vehicle battery
that has sufficient current capacity. If the current to the transceiver
is insufficient, the display may darken during transmission, or
transmitting output power may drop excessively. Your transceiver is
delivery with cigar plug. In case of direct connection with battery :
1.
Route the DC power cable supplied with the transceiver directly
to the vehicle's battery terminals using the shortest path from
the transceiver.
• The entire length of the cable must be dressed so it is isolated from
heat, moisture, and the engine secondary (high voltage) ignition
system/ cables.
2.
After installing cable, in order to avoid the risk of damp, please
use heat-resistant tap to tie together with fuse box. Don't forget
to reinforce whole cable.
»
Locate the power input connector as close to the transceiver as
possible.
3.2 Intall Microphone Hanger
1. Choose idea location and mark for screw point.
2.
Fix the hanger by the srews in accessory list.
