14
5.3 Professional Transceiver Mode
When set display mode as "CH", it enters into Professional
Transceiver mode. At this mode, except scan, other shortcut operation
can't operate. And from No.1-10 menu in function setting will be auto
hidden. They should be set by PC software. If there is corresponding
name for current channel, the LCD will display current channel name
Otherwise, it shows current channel number.
5.4 Under Every Mode
From No. 11-20 menu in general setting can be changed and saved.
6. BASIC OPERATION
6.01 Switching the Power On/Off
When the transceiver in power off, press [VOL] key to power on or
base on function menu APO set as power on once connect the power,
then hold [VOL] key for 2 seconds to power off.
6.02 Power Voltage Display Function
After the transceiver connect the power cable, press [FUN] key and
[SQL] key same time for 1 second can conrm current power voltage,
then you can see the voltage data from the LCD display. The LCD
display voltage will change once the power voltage has changed.
»
If transceiver programmed as professional transceiver mode
and locked, you can't return to amateur transceiver mode by
manual operation from general setting.
»
The display voltage range is from 9V to 17V, the display data is
a rough data, if you need exactly data pls use the voltmeter to
test.
