3. INITIAL INSTALLATION
To install the transceiver, select a safe, convenient location inside
your vehicle that minimizes danger to your passengers and yourself
while the vehicle is in motion. Consider installing the unit at an
appropriate position so that knees or legs will not strike it during
sudden braking of your vehicle. Try to pick a well ventilated location
that is shielded from direct sunlight.
Double
check that all screws are tightened to prevent
vibration from loosening the bracket or transceiver.
Car body
Washer
(M5)
Tapping
screw
(M5x20mm)
Mounting bracket
2.
Position the transceiver, then insert and tighten the supplied
hexagon SEMS screws.
1.
Install the mounting bracket in the using the supplied self-
tapping
screws (2pcs) and at washers (2pcs).
V
O
L
3.1 Mobile Installation
