Single Engine Velvet Drive In-Line Installation
- (1:1, 1.52:1, 2.57:1 or 2.91:1 Ratio)
The transmission output shaft rotation is the same as the
engine rotation. A LH (CCW) rotation engine requires a
LH propeller.
Figure 9 Single Engine Velvet Drive in-Line Installation
- 1:1, 1.52:1, 2.57:1 or 2.91:1 Ratio
LH
FRONT
LH OR CCW
ENGINE
ROTATION
FLYWHEEL
