Single Engine Velvet Drive In-Line Installation
- (1.90:1 Ratio)
The transmission output shaft rotation is the opposite
of the engine rotation. A LH (CCW) rotation engine
requires a RH propeller.
Figure 10 Single Engine Velvet Drive in-Line Installation
- 1.90:1 Ratio
Single Engine V-Drive Installation
The transmission output shaft rotation is the opposite
of the engine rotation. A LH (CCW) rotation engine
requires a RH propeller.
Figure 11 Single Engine V-Drive Installation
RH
FRONT
LH OR CCW
ENGINE
ROTATION
FLYWHEEL
FLYWHEEL
LH OR CCW
ENGINE
ROTATION
FRONT
INPUT
GEAR
ROTATION
OUTPUT
FLANGE
ROTATION
RH
