Chapter 4. SNMP
4.6.1 Configure the SNMP Agent
From the 'SNMP Configuration' menu select "1", SNMP Agent Configuration.
Item number 1, IP address is the IP address that the SNMP card will answer to when
"pinged", Telnet'd, TFTP'd or when accessed by SNMP.
Item number 2, is the subnet mask for the network that the card is attached to.
Item number 3, is the default gateway for the network that the card is attached to and is
required if the FMUX04 is to be managed from a different subnet.
HINT: when entering IP addresses, enter without "dots" and include any leading zeros.
For example, the above IP address 172.24.1.11 would be entered as 172024001011 while
10.0.0.1 would be entered as 010000000001.
4.6.2 Manager Configuration
From the 'SNMP Configuration' menu, select item "2", Manager Configuration. Manager
configuration is required to tell the agent (the SNMP card) who has authority to access the
SNMP via "Get" commands (read) or "Set" commands (write) and where to send "trap"
messages (unsolicited messages that are usually generated by alarms in the FMUX04).
LOCAL << SNMP Agent Configuration >>
1. IP Address [172. 24. 1. 11]
2. Subnet Mask [255.255. 0. 0]
3. Gateway IP [172. 24.190.254]
Press <ESC> to previous menu.
LOCAL << Manager Configuration >>
1. Access IP #1 [172. 24. 1.125] [Community String #1] [trap]
2. Access IP #2 [192.168. 0. 15] [Community String #2] [trap]
3. Access IP #3 [172. 24. 1.126] [Community String #2] [ ]
4. Access IP #4 [192.168. 0. 49] [Community String #2] [ ]
5. Community String #1 (Read/Write)[secret]
6. Community String #2 (Read Only) [public]
Press <ESC> to previous menu.
40
