Chapter 2. Installation
Chapter 2. Installation
2.1 General
The Installation chapter will cover the physical installation of the FMUX04, Standalone/Rack
Mount Fiber Optical Multiplexer, the electrical connections, interface connections and
cabling requirements. A brief overview of the functional components such as main unit, order
wire option and management options will also be outlined in this chapter.
Required Tools
You will need these tools to install the FMUX04:
Number 2 Phillips screwdriver for the 3mm and the 12-24 rack installation screws.
Wrist strap or other personal grounding device to prevent ESD occurrences.
Antistatic mat or antistatic foam to set the equipment on.
2.2 Site Preparation
Install the FMUX04 within reach of an easily accessible grounded AC outlet or site DC
power. The outlet should be capable of furnishing 100 to 240 VAC (18 to 36VDC or 36 to 72
VDC for DC supply). Allow at least 10cm (4 inch) clearance at the rear and front of the
FMUX04 for power lines and interface cables.
2.3 Unpacking
17
Inner cover
Transceiver
Cables
Outer cover
Figure 2-1. Unpacking the FMUX04.
