RZT-S Zero
118
Battery removal/installation
To remove/replace the batteries:
1. Disconnect the battery pack’s positive lead from the
contactor assembly:
1a. Remove the three screws, indicated by the
arrows in Figure 6.5, that hold the left access
cover in place using a 1/2” wrench.
This mower has four batteries that need to be installed. They must be installed in a specific
order to minimize shorting hazards and to prevent improper wiring of the system.
Never let the battery terminals or any live harness connection contact the frame.
#ONTROLPANEL
"ATTERY
"ATTERY
"ATTERY
"ATTERY
