9
2. Remove the two screws, indicated by the arrows in
Figure 2.10, from the underside of the pod using a
3/8” wrench.
3. Remove the rear battery cover by following the pro-
cedures described in Chapter 6: Battery Pack and
Charger.
4. Remove the two screws, indicated by the arrows in
Figure 2.11, from the inboard side of the pod using a
T-30 torx driver.
5. Disconnect the charger harness.
6. Remove the screw from the front of the pod using a
T-30 torx driver.
See Figure 2.12.
Figure 2.10
Figure 2.11
Charger harness
Figure 2.12
Screw
