Cub Cadet RZT-S Zero Shop Manual

RZT-S Zero
64
• DC Motor
: These motors use DC voltage
pulses that will go in one phase as a positive
pulse and leave another as a negative pulse.
The inputs and outputs are constantly switching
so that one phase will be positive, one will be
negative and the third phase will be zero.
See Figure 5.16.







5
6
7






Figure 5.16
