CUDA 2848 - Front View Parts List

8.930-369.0 • 2848 • Rev. 4/13a
35
PARTS WASHER
OPERATOR’S MANUAL
EXPLODED FRONT VIEW PARTS LIST
ITEM PART NO. DESCRIPTION QTY
1 8.915-208.0 Assy, Cabinet 2848 1
8.915-447.0 Assy, Cabinet 2848 w/12"
HGT Ext 1
2 8.915-213.0 Assy, Door 2848 1
8.915-452.0 Assy, Door 2848 w/12" Ext 1
3 8.915-141.0 Assy, Turntable 2848 1
4 8.915-606.0 Assy, Debris Tray 1
5 8.930-275.0 Cover, Sump 10" x 16.5"
w/o Gauge 1
6 9.804-346.0 Bearing, Ball Upper TT
6206RS 1
7 9.804-347.0 Bearing, Ball Lower TT
6007RS 1
8 8.713-234.0 Spindle, Turntable
2216-2848 1
9 8.712-909.0 Washer Lock 3/4 1
10 8.712-855.0 Bolt, 3/4", -16 x 1-1/2" Grade
2 Hex Head 1
11 8.712-875.0 Pin Cotter 1/8" x 1-1/4" 4
12 8.712-939.0 Pin Clevis 3/4" x 3-1/2" 4
13 8.713-037.0 Wheel Polyolefin 4" x 2" x 3/4"
Bore 4
14 9.804-378.0 Latch, Sump Cover 2
15 8.706-349.0 Pipe, Cap, 1-1/2" Galv. 1
16 8.712-928.0 Spindle, Door 1
17 8.930-238.0 Spacer, Door Hub 1
18 8.713-821.0 Nut, Nyloc, 5/8"-18 Zinc GR5 1
19 8.712-952.0 Grease Fitting 1
20 8.930-242.0 Assy, Door Latch 1
21 8.915-372.0 Angle, Door Side 2848 1
8.915-446.0 Angle, Door Side 2848
w/12" Ext 1
22 8.915-200.0 Angle, Door Top 2848 1
23 8.712-951.0 Foam Strip 1/8" x 1" Adhesive
Back 64"
w/12" Hgt Ext 76"
24 8.714-150.0 Chain 1
ITEM PART NO. DESCRIPTION QTY
25 9.802-807.0 Washer, 3/8" SAE Flat 3
26 8.915-388.0 Seal, Bulb Type Epdm Side
Profile 68"
w/12" Hgt Ext 80"
27 8.718-794.0 Screw, 10/32" x 3/4", HEX SS 17
w/12" HGT Ext 20
28 9.802-802.0 Washer, 1/4", FLAT, SAE 17
w/12" HGT Ext 20
29 9.804-567.0 Nut, 10/32", ESNA 17
w/12" HGT Ext 20
30 8.713-038.0 Wheel, Track 6
31 8.713-266.0 E-Clip, 1/4" Mild Steel 12
32 8.718-603.0 Bolt, 1/4" x 3/4", NC HH SS 3
33 8.718-965.0 Washer, 1/4", FLAT, SAE, SS 6
34 9.802-774.0 Nut, 1/4", ESNA, NC 5
35 8.718-568.0 Washer, 1/4" FLAT SS
Sealing Rub 4
36 9.802-779.0 Nut, 3/8", ESNA, NC 3
37 8.921-304.0 Latch, Spray Pipe 1
38 8.713-020.0 Spring- Extension. 440 Dia. x 2",
6.5 lb/inch 1
39 9.804-373.0 U-Bolt, 1/4"-20 Plated 1
40 8.930-307.0 Stop Spray Pipe 1
41 8.713-246.0 Screw -5/16"-18 x 1"
Socket Head 2
42 8.718-980.0 Washer, 5/16", Flat, SAE 2
43 9.802-776.0 Nut, 5/16", ESNA, NC 2
44 8.915-388.0 Seal, Bulb Type Epdm
Side Profile 48"
45 9.801-126.0 Label, Cuda, 24 x 6" 1
46 9.801-132.0 Label, Cuda Icon, 6" 1
47 9.804-370.0 Sleeve, Vinyl 1
48 8.713-265.0 Cap, Vinyl Black, 1/4" x 3/4" LG 6
49 9.804-203.0 Handle, Strainer 1
