APPENDIX D
Curtis 1239E-1269E Manual, os 37.0 RevA – May 2021
Return to TOC
pg. 156
Maximum current (A rms) 550 650 500 650
S2–60 minute current (A rms) 155 190 135 200
Continuous current for design life (A rms) 175 175 170 175
Notes: All current ratings are rms values per motor phase.
S2–60 minute current is the typical current achievable before thermal cutback occurs, with an ambient temperature of 25°C and the controller
mounted to a 6 mm thick vertical steel plate with 6 km/h (1.7 m/s) airflow perpendicular to the plate.
Continuous current for design life is the maximum long-term current, at an internal heatsink long-term temperature of 70°C (158°F), at which the
controller will achieve its design life. These numbers are often calculated for a given application by determining an rms duty cycle current and heatsink
temperature. For applications that exceed this, please contact the Curtis distributor or support engineer.
