Return to TOC Curtis 1239E-1269E Manual, os 37.0 RevA – May 2021
2 — INSTALLATION AND WIRING
pg. 5
2X 13.5
328.50
58
103
206.90 2X 15.0
9.0
3X
11.0
R10 TYP
8.4
148
18.3
6
5
4
Part Number: XXXXXXXX MODEL: XXXXXXXXX VOLTAGE: XXXXXXX CURRENT: XXXX Serial Number: XXXXXXXXXXX
237
93
19.0
125
128
Figure 4
Mounting dimensions
in millimeters (mm)
for the Curtis 1269E
motor controller.
Take the required steps during the design and development of the end product to ensure that its
EMC performance complies with applicable regulations; suggestions are presented in Appendix A.
The controllers contains ESD-sensitive components. Use appropriate precautions in connecting,
disconnecting, and handling the controller. See installation suggestions in Appendix A for protecting
the controller from ESD damage.
