Curtis 1244-64 series User Manual

Curtis 1244 Manual, Rev. E
69
Parameters Menu Notes
1
Control modes (for detail, see Section 3: Programmable Parameters, page 28)
Type 0: Current control mode—throttle controls motor torque
Type 1: Voltage control mode—throttle controls motor speed
2
rottle types (for detail, see rottle Wiring in Section 2)
Type 1: 5kΩ–0
Type 2: single-ended 0–5V, 3-wire pot, current source, and electronic throttles
Type 3: 0–5kΩ
Type 4: wigwag 0–5V and 3-wire pot
Type 5: CAN-Nodes type throttles
3
HPD types (for detail, see Section 3: Programmable Parameters, page 41)
Type 0: no HPD
Type 1: HPD unless KSI and interlock inputs received before throttle request
Type 2: HPD unless KSI input is received before throttle request
Type 3: HPD unless KSI and interlock and direction inputs received before
throttle request
4
SRO types (for detail, see Section 3: Programmable Parameters, page 42)
Type 0: no SRO
Type 1: SRO unless interlock input is received before a direction is selected
Type 2: SRO unless KSI + interlock inputs received before direction selected
Type 3: SRO unless KSI + interlock + forward inputs received in that order
5
Fault output types (for detail, see Section 3: Programmable Parameters, page 43)
On: Fault Code format
O: Fault Category format
7 — PROGRAMMER MENUS
