3. PRINTER FUNCTIONS3. PRINTER FUNCTIONS
KPM216H
133-
[Example]
HnLnv(CSE
[Name] Set relative vertical print position
[Format] ASCII ESC ( v nL nH
Hex 1B 28 76 nL nH
Decimal 27 10 118 nL nH
[Range] 0 ≤ nL ≤ 255
0 ≤ nH ≤ 255
[Description] Sets the print vertical position based on the current position by using the
horizontal or vertical motion unit.
• This command sets the distance from the current position to [( nL + nH x
256) x ( horizontal or vertical motion unit)].
[Notes] • When the starting position is specified by N motion unit to the bottom :
nL + nH x 256 = N
When the starting position is specified by N motion unit to the top (negative
direction), use the complement of 65536 :
nL + nH x 256 = 65536 - N
• The horizzontal and vertical motion unit are specified by GS P.
• The GS P command can change the horizontal (and vertical) motion unit.
However, the value cannot be less than the minimum horizontal movement
amount.
• In standard mode, the vertical motion unit is used.
[Default]
[Reference] GS P
[Example]
