Custom Audio Electronics KPM180H - Page 30

KPM180H (models with presenter)

use six M3 screws.
663032.5
90
6 x M3
A
A
B
B
B
B
Additionally, the panel must provide an opening for dust of paper that meets the following measures (in millimetres):
min. 34
4545
min. 9
7.5
30
