max 5
SP
Detail A
max 10SP
Detail B
Device chassis
Fixing panel
Fixing screw
Device chassis
Fixing panel
Fixing screw



For example, if panel thickness is 10mm (Sp = 10mm), The maximum screw length will be 15mm (detail A) or 20mm (detail B).
