Paper with black mark on the thermal side of paper (only with VKP80III emulation enabled)
The following image shows a sample of paper with the black mark printed on the thermal side. Use this kind of tickets if
the upper black mark sensor (optional) is installed on the right paper cursor.
For models with the upper black mark sensor (optional) installed on the left cursor, the ticket will be symmetrical to its
longitudinal axis.
For more information about the use of tickets with black mark see chapter 7.
7
5
+1
0
min 70
min 9
+1
0
PAPER WIDTH from 50 to 82.5
THERMAL SIDE
109
