9 SPECIFICATION
9.1
GENERAL
Sensors
Paper presence in input, ticket paper presence in output, head temperature,
ejector position, mobile detector for black mark on the non-thermal side of
barcode reader (optional), printing unit open, tilting bulkhead position,
low paper on external paper roll holder (optional)
Emulations
VKP80II
VKP80III
Printing driver
Windows XP
Windows VISTA (32/64 bit)
Windows 7 (32/64 bit)
Windows 8 (32/64 bit)
Windows 8.1 (32/64 bit)
Windows 10 (32/64 bit)
OPOS
Linux (32/64 bit)
Android
iOS
INTERFACES
RS232 serial port
(only for VKP80III LAT and VKP80III REAR)
from 1200 bps to 115 200 bps
USB port 12 Mbit/s (USB 2.0 full speed)
Ethernet port
(only for VKP80III ETH)
10 Mbit/s, 100 Mbit/s
MEMORIES
Receive buffer 2 kB
Flash memory 1 MB internal + 4 MB external (of which 1 MB available)
RAM memory 128 kB internal + 8 MB external
97
