6.4 Printhead status
The device performs the printhead operating status when printing the setup report. The total number of dots is reported
PRINTER SETTINGS
1 «••••••••» 640
----------------------------------------------------------------------------
PRINTHEAD WORKING GOOD!
PRINTER TYPE ....................................<device model>
Barcode Reader ....................................Not present
LED bar RGB (hardware) ......................Not present
PRINTING HEAD TYPE........................<head model>
INTERFACE ..........................................USB
PROGRAM MEMORY TEST.................OK
DYNAMIC RAM TEST...........................OK
Total no.
printhead dots
no damaged
dots
PRINTER SETTINGS
1 •••••••• 640
--------------------------------------------------------------------------
DEFECTED PRINTHEAD DOTS = 4
DOT POSITION : 2
DOT POSITION : 11
DOT POSITION : 43
DOT POSITION : 72
Total no.
printhead dots
List of
damaged dots
69
