6.6 Communication parameters
The parameters marked with the symbol
D
are the default values.
Settings remain active even after the device has been turned off and they are stored in non-volatile memory.
RS232 BAUD RATE Communication speed of the serial interface:
1200 9600 57600
2400 19200 115200
D
4800 38400
This parameter is valid only for VKP80III LAT and VKP80III REAR with serial interface.
RS232 DATA LENGTH Number of bit used for characters encoding:
7 bits/car
8 bits/car
D
This parameter is valid only for VKP80III LAT and VKP80III REAR with serial interface.
RS232 PARITY Bit for the parity control of the serial interface:
None
D
= parity bit omitted
Even = even value for parity bit
Odd = odd value for parity bit
This parameter is valid only for VKP80III LAT and VKP80III REAR with serial interface.
RS232 HANDSHAKING Handshaking:
XON/XOFF = software handshaking
Hardware
D
= hardware handshaking (CTS/RTS)
This parameter is valid only for VKP80III LAT and VKP80III REAR with serial interface.
NOTE:
When the receive buffer is full, if handshaking is set to XON/XOFF, the device sends
the XOFF (0x13) on the serial port. When the receive buffer has cleared once again, if
handshaking is set to XON/XOFF, the device sends the XON (0x11) on the serial port.
BUSY CONDITION Activation mode for Busy signal:
OffLine/ RXFull = Busy signal is activated when the device is both in OffLine status and
the buffer is full
RXFull
D
= Busy signal is activated when the buffer is full
This parameter is valid only for VKP80III LAT and VKP80III REAR with serial interface.
USB ADDRESS NUMBER
than a USB device connected with the same PC):
0
D
2 4 6 8
1 3 5 7 9
71
