3.2 Device components: external views
VKP80III LAT
1. Device cover
2. Opening lever
3. Paper output
4. Right cursor for paper input
5. Paper input
6. Left cursor for paper input
7. FORM FEED key
8. LINE FEED key
9. Port for low paper sensor (external)
10. Expansion port (for optional external device)
11. Product label
12. Status LED
13. RS232 port
14. USB port
15. Power supply port
1 2
3
54 6
8 7910
14 13 1215
11
14
