3.7 Status messages
The status LED indicates hardware status of device. Given in the table below are the various LED signals and the cor-
responding device status.
STATUS LED DESCRIPTION
- OFF DEVICE OFF
GREEN ON DEVICE ON: NO ERROR
GREEN
COMMUNICATION
STATUS
x 1 RECEIVE DATA
x 2
RECEPTION ERROR
(PARITY, FRAME ERROR, OVERRUN ERROR)
x 3 COMMAND NOT RECOGNIZED
x 4 COMMAND RECEPTION TIME OUT
YELLOW
RECOVERABLE
ERROR
x 2 PRINTHEAD OVERHEATED
x 3 PAPER END
x 4 PAPER JAM
x 5 POWER SUPPLY VOLTAGE INCORRECT
x 6 COVER OPEN
RED
UNRECOVERABLE
ERROR
x 1 EJECTOR ROLLER ERROR
x 2 EJECTOR BULKHEAD ERROR
x 3 RAM ERROR
x 4 EXTERNAL FLASH ERROR
x 5 AUTOCUTTER ERROR
22
