3.3 Device components: internal views
1. Ejector bulkhead
2. Upper left sensor for black mark (optional)
3. Printing head with sensor for paper in presence (built-in)
4. Barcode reader (optional)
5. Paper out presence sensor
6. Upper right sensor for black mark (optional)
7. Lower mobile sensor for black mark
8. Autocutter
3 5421
678
17
