Paper with black mark on the non-thermal side
In standard model, the detection of black mark is performed
on the non-thermal side of paper by the mobile sensor.
direction
of paper
feed
Sensor 1Non-thermal
side
Paper with black mark on the thermal side
In model with optional sensor, the detection of black mark is
direction
of paper
feed
Thermal
side
Sensor 2
(optional)
81
