Paper weight from 60 g/m
2
to 110 g/m
2
Recommended types of paper
KANZAN KF50, KP460 and KP390
MITSUBISHI PF5067, TL4000 and TF1067
Minimum ticket length
70 mm
(using the command 0x1D 0xE8 it can be decreased up to 54 mm)
Paper end Not attached to roll core
External roll diameter
(6)
max. 150 mm
External roll core diameter 25 mm
Core type Cardboard or plastic
AUTOCUTTER
Paper cut Total cut
Estimated life
(1)
1000000 cuts
DEVICE ELECTRICAL SPECIFICATIONS
Power supply 24 Vdc ±10% (optional external power supply)
Typical consumption
(5)
1 A
Medium consumption
(7)
1.5 A
Standby consumption
VKP80III LAT
VKP80III REAR
0.04 A
VKP80III ETH 0.08 A
ELECTRICAL SPECIFICATIONS POWER SUPPLY code 963GE020000053 (optional)
Power supply voltage from 100 Vac to 240 Vac
Frequency from 50 Hz to 60 Hz
Output 24 V, 2.5 A
Power 60 W
99
