VERTICAL SCALE [%]
Adjust of the printing positions by adding the percentage value to the coordinates of
elements (in the direction of the length of the ticket).
The numeric value of the adjustment is made up with the following four parameters
for the setting of three digits (two for the integer part of the number and one for the
decimal part) and of the sign:
VERTICAL SCALE SIGN
Sign setting:
+
D
= positive percentage value
- = negative percentage value
VERTICAL SCALE [% x 10]
Setting the digit for tens:
0
D
4 8
1 5 9
2 6
3 7
VERTICAL SCALE [% x 1]
Setting the digit for units:
0
D
4 8
1 5 9
2 6
3 7
VERTICAL SCALE [% x .1]
Setting the digit for decimals:
0
D
4 8
1 5 9
2 6
3 7
NOTE: For example, to set the Vertical Scale to 15%, modify the parameters as follows:
Vertical Scale Sign = +
Vertical Scale [% x 10] = 1
Vertical Scale [% x 1] = 5
Vertical Scale [% x .1] = 0
5. CONFIGURATION
