DNC <-> PC STATUS TEST
TRANSFER 1 1, 2 Cyback
3,4 TEST LIAISON 1 2
7 FLASH
8 EXT KEYBOARD
10 ARDIS CONNEXION
11 INTERNAL BACKUP
12 INTERNAL RESTORE
Quantity of free backup memory 97 %
-- RS232 PARAMETERS --
Baud rate 57600 Stop 1.0
Internal backup
0 = Abort
1 = Save machine parameters
2 = Save tools
Parity odd (1) EVEN (0) _ Bits 8
• Select the operation to do by pressing the 0, 1 or 2 key.
e ? is displayed at the top right of the screen (as
to change to level 2 or 3).
Introduce the level 4 code for the machine parameters or the 217
code for the tools.
The pop-up is closing.
• The message valu
• Press the
key.
DNC <-> PC STATUS
TRANSFER 1 1, 2 Cyback
3,4 TEST LIAISON 1 2
7 FLASH
8 EXT KEYBOARD
11 INTERNAL BACKUP
12 INTERNAL RESTORE
Quantity of free backup memory 93 %
-- RS232 PARAMETERS --
Baud rate 57600 Stop 1.0
Parity odd (1) EVEN (0) _ Bits 8
When the backup has finished, the EXECUTE message and the new free
memory percentage are displayed.
MAINTENANCE PAGE 99
