CYBELEC DNC 600S - Main Menu Options

APPENDIX C: THE MAIN MENU PAGE 31
MAIN MENU OPTIONS
1 NEW PRODUCT
Create a new product and display the page sequence,
ready for entering the data.
2 EASY BEND
Access ///ADD CROSS REFERENCE
Allows for quickly programming a bend and/or
stopping production to quickly do another job (bend)
without loss or modification of the program in hand.
3 LIST OF
PRODUCTS
/CRITERIA
This double page displays the list of parts held in DNC
memory and allows for selectively seeking parts.
4 LIST OF PUNCHES
Displays the list of the punches.
5 LIST OF DIES
Displays the list of thedies.
6 PROGR. PUNCH /
DIE
From this page, it is possible to recall, program or
delete a die or a punch.
7 PRODUCT
PUNCHES / DIES
This page allows to modify, for the product only, the
reference of a tool.
8 L-ALPHA
PRODUCT
Generally called L-alpha page, this page displays and
allows the programming of products in "lengths and
angles" mode.
9 BEND SEQUENCE
Displays the page allowing to program or modify the
bending order.
10 USER
PARAMETERS
(KEY 2)
Lets you edit user parameters and materials
preferences.
11 PROGR. AXES
DATUM
Allows to program the axis position counter.
12 TRANSFER
DNC <-> PC
Allows the global or partial two way transfer of
products, tools or machine parameters between the
fixed internal memory and a PC.
13 MACHINE
PARAMETERS
VIEWER
Displays all machine parameter pages.
Caution: you cannot edit machine parameters using this
menu option.
