AP G THE CURRENT SCREEN PENDIX I: PRINTIN
The DNC 600S authorizes, if the RS232 port is included (optional), to print
the content of a page displayed on the screen (connector J5).
This allows, through a hardcopy, to retain information regarding the
product(s), tools or machine parameters.
To be able to nd this information to the printer, it is compulsory that you
nter (RS232).
You have to program the DNC 600S transmission parameters to the printer's
Stop bits: 1, 2 etc.
Parity: 1 or leave blank
Protocol : this field defines how many DNC's pages you want to have
on one printer's page. After the relevant number the DNC
sends a form feed character.
Example: 1 = 1 DNC's page per printer'spage.
2 = 2 DNC's pages per printer's page, etc.
BCC: this field defines the left margin in cm.
left margin = 2 + (BCC x 2)
Valid range: 0 (2 space characters) to 9 (20 space characters)
Example: BCC = 4, then 2 + (4 x 2) = 10
TO PRINT FROM THE DNC
se
use a serial pri
required specifications.
Baud rate: 4800 max.
Bits: 7 or 8
Select the relevant page.
Simultaneously press the stop and correction
or menu
keys.
PAGE 82 USER GUIDE DNC 600S
