APPENDIX A: CONVENTIONS
As a general rule, in this manual we will not repeat how to validate a field,
select a tool, call a page or any other basic manipulations.
These informations are described at the beginning of this manual.
TYPOGRAPHICAL CONVENTIONS
Arial bold Quotations of text as seen on the screen.
Arial bold italic Used to indicate the name of a DNC input or
output.
Italic Reference to a written element, a paragraph or a
manual.
For example: See ///ADD CROSS
REFERENCE.
ABBREVIATIONS / GLOSSARY
Explications of the abbreviations which are not visible fields in the pages of
the numerical control.
TDC Top dead centre.
SWP Switch point of speed, i.e. the change from
approach speed in bending speed in the descent
phase.
PSS Safety point. This point is calculated in function
of the tools height and the material thickness.
PP Pinch point (see page 60).
BDC Bottom dead centre
LED Light Emitting Diode. Small red light serving as
luminous indicator.
PAGE 22 USER GUIDE DNC 600S
