CYBELEC DNC 600S - DEFINING THE BENDING ORDER

DEFINING THE BENDING ORDER
Press the key, to display the bending order page (Choice 9, BEND
SEQUENCE of the main menu).
P 1 N 1 p/d 1/ 1
BEND 1 2 3 4 5 6 7 8 9 10
__ __ __ __ __ __ __ __ __ __
LEG __ __ __ __ __ __ __ __ __ __
Field Overview
N
Number of the sequence.
FACE
Face number.
LEG
Number of the face which will press against
the stop.
The orientation of the legs is made as a
function of the bending order.
CR
Number of bends requested when working
with step bending .
PAGE 46 USER GUIDE DNC 600S
