CYBELEC DNC 600S - Page 77

Procedure to Perform an Ideal Curve
In this exa , an ideal curve with an internal radius of 50 mm is to be
made.
 Ca L-ALPHA PRODUCT page and fill in the fields in ord
mple
ll the er to
make the bend illustrated below.
P 0 P+ ___ N 1 I/mm
CODE CAL_/__.__
p/d 1/ 1 St:1 Al:_ SS:_
Th: 2.00 Kg/mm² 45.000
Lmat 2000 Dev L ___.__
-N- -L- - - -p/d- -ri- CR
1 100.00 90.0°__/__ 50 00 15 ___
2 200.00 90.0°__/__ ____.__ __ ___
3 100.00 ____._°__/__ ____.__ __ ___
4 ____.__ ____._°__/__ ____.__ __ ___
5 ____.__ ____._°__/__ ____.__ __ ___
____.__ ____._°__/__ ____.__ __ ___
 Press the key.
Th e e system fills in th Dev L, and ri fields.
PAGE 68 USER GUIDE DNC 600S
